CADfeature is a high-quality, efficient, automatic
and feature-based parametric translation system with the scalability to address
the needs of individual users to globe enterprises.
1. Robust feature mapping between major CAD systems
2. Data mining option to predict translation success/fail ratio prior to running actual translation.
3. The software will output B-rep features when the feature translation fails, so that users only need to repair one feature manually instead of all the remaining features in the feature weight.
4. Guarantee the correct position of each standard part in the assembly when translating the assembly containing standard parts.
5. Direct PDM integration with Teamcenter Engineering..
6. Incremental translation part tracking to avoid duplicate part processing. This function significantly reduces the translation time of part family and the translation efficiency of common parts and assemblies.
7. Advanced quality checking routines report textual CAD quality data as well as visual models in a 3D viewer.8. Associative 2D drawing and layout translation includes in QA reporting
9. Use the result validation tool to compare the original and result data to ensure the accuracy of geometry and characteristics of all parts.
1. 2D drawing information is as follows: when the related 3D parts and assemblies are changed, the page, view, layout and proportion, annotation and size can be automatically updated.
2. 3D parametric model information such as: Assembly constraints, sketches with dimensions and geometric constraints, datum and reference geometry, Boolean operations, extruded features, drafts, lofts, sweeps, rounds, fillets, chamfers, surface feature operators, holes, shells, transformations, patterns, system and user attributes and etc.
3. 3D annotation and view (also known as PMI, product manufacturing information).
1、Dassault: CATIA V4, V5, SolidWorks
2、Autodesk:Inventor
3、PTC: Pro / ENGINEER, Creo, CoCreate
4、Siemens PLM: I‐DEAS NX, NX
